Description
Diesel Engine-driven DC Welder / Three-phase AC Generator
Sound Proof Type
DLW-300LS
DLW-300LS
| Model | DLW-300LS | ||
| Welding Current Range (A) | 30 – 280 | 30 – 300 | |
| Applicable Electrode (mm) | 2.0 – 6.0 | ||
| Rated Duty Cycle (%) | 100 | ||
| AC Power Frequency (Hz) | 50 | 60 | |
| AC Power Rated Output (kVA) | 3-phase 10.4 | 3phase 11.4 | |
| AC Power Rated Voltage (V) | 200/220/230/240 or 380/440 | ||
| Engine Model | YANMAR 3-3TNM68G | ||
| Rated Output (kW/rpm) | 12.5/3000 | 15.0/3600 | |
| Fuel Consumption (L/h) | 1.96 | 2.34 | |
| Fuel Tank Capacity (L) | 36 | ||
| Dimensions (L x W x H) (mm) | 1410 x 560 x 770 | ||
| Dry Weight (kg) | 379 | ||
| Sound Level (7mdB(A)) | 63 | 65 | |
